Banana Pi BPI-M2 Zero With Allwinner H3(Option H2 Plus H5)Chip Design With 512M RAM (Raspberry Pi ) Microprocessor Development Board

Send Inquiry

Request To Call Back

Banana Pi BPI-M2 Zero With Allwinner H3(Option H2 Plus H5)Chip Design With 512M RAM (Raspberry Pi ) Microprocessor Development Board

Name: Banana Pi BPI-M2 Zero With Allwinner H3(Option H2 Plus H5)Chip Design With 512M RAM (Raspberry Pi ) Microprocessor Development Board
Brand: ROBOTICS EMBEDDED EDUCATION SERVICES PRIVATE LIMITED
Price: 3010 INR
Availability: InStock

Price 3010 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Banana Pi BPI-M2 Zero With Allwinner H3(Option H2 Plus H5)Chip Design With 512M RAM (Raspberry Pi ) Microprocessor Development Board Specification

Display Type
Supports HDMI output

IP Rating
Not rated (for indoor use)

Interface
HDMI, Micro USB, 40 GPIO pins, MicroSD, USB 2.0

Charging Voltage
Not applicable (powered via USB)

Response Time
Dependent on OS and application

Components
Allwinner H3 (option for H2+ or H5), 512M RAM, HDMI port, 40-pin GPIO, MicroSD slot, Wi-Fi module, Micro USB OTG, USB 2.0, IR receiver

Processor Speed
1.2 GHz (quad-core Cortex-A7)

Power Supply
Micro USB power supply

Features
Compact size, wireless connectivity (Wi-Fi), GPIO ports for expansion, compatible with multiple chips (H3/H2+/H5)

Sensors Specification
Supports compatible external sensors via GPIO

Resolution
HDMI output up to 1080p

Thermal Conductivity
Active and passive cooling supported

Power Source
USB powered

Output
HDMI, AV, GPIO, USB

Input
Micro USB, GPIO interface

Usage
Electronics

Operating Temperature
0°C to 60°C

Product Type
Microprocessor Board

Application
Industrial

Rated Voltage
5V DC

Supply Voltage
5V

Size
65mm x 30mm

Dimension (L*W*H)
65mm x 30mm x 5mm

Function
Single-board microcomputer for embedded systems, prototyping, and IoT development

Color
Blue

Weight
Approximately 30g

Warranty
1 year

Current Rating
Typical 1A - 2A

Thickness
Approx. 5mm (main board)

Capacity
512MB DDR3 RAM

Frequency
CPU up to 1.2 GHz

Audio Output
HDMI audio, AV audio

Software Support
Supports Linux distributions (Raspbian, Ubuntu, Debian, etc.), Android

HDMI Version
HDMI 1.4

LED Indicators
Power, status

GPIO Header
40-pin, Raspberry Pi compatible

IR Receiver
Onboard

Expansion Capability
Multiple HATs and peripheral support via GPIO

USB Ports
1 x USB 2.0, 1 x Micro USB OTG

Form Factor
Raspberry Pi Zero compatible

Graphics
Mali-400 MP2 GPU

Bluetooth
No onboard Bluetooth

AV Output
Yes, via board connector

Wi-Fi
802.11 b/g/n (2.4GHz), onboard

Operating System
Supports multiple Linux distributions and Android

Board Material
FR4 PCB with ENIG finish

Storage Support
MicroSD card slot (up to 128GB)

CPU Architecture
ARM Cortex-A7 quad-core

Banana Pi BPI-M2 Zero With Allwinner H3(Option H2 Plus H5)Chip Design With 512M RAM (Raspberry Pi ) Microprocessor Development Board About

Ending Soon: Seize instant savings by reserving your prodigious Banana Pi BPI-M2 Zero board, crafted with a valiant Allwinner H3 (option for potent H2+ or H5) chipset and 512M RAM. Offering quad-core Cortex-A7 power, Wi-Fi 802.11 b/g/n, HDMI output, and a formidable 40-pin GPIO expansion, it excels for embedded, prototyping, and IoT development. With broad software support and robust FR4 PCB build, this compact microcomputer is engineered for versatile industrial and experimental applications. Act quickly-quantities are limited!

Versatile Applications and User Base

The Banana Pi BPI-M2 Zero equips engineers, electronics hobbyists, educational institutions, and developers with a resilient platform for industrial control, smart home automation, IoT devices, and prototyping. Used by students and professionals alike, its site of application ranges from classrooms and research labs to industrial automation settings. Its compatibility with Raspberry Pi accessories and Linux-based systems broadens usage, facilitating innovation in automation, testing, and product development.

Supply Ability, Certifications, and Domestic Market

With a strong supply ability and secure packaging, the Banana Pi BPI-M2 Zero is readily available at an appealing sale price. Exchanges support distributor and wholesaler operations across the main domestic market of India. The board complies with relevant safety and performance certifications, ensuring quality and reliability. Each unit is meticulously packaged, safeguarding its components during transit, and making it ideal for bulk supply or localized distribution.

FAQ's of Banana Pi BPI-M2 Zero With Allwinner H3(Option H2 Plus H5)Chip Design With 512M RAM (Raspberry Pi ) Microprocessor Development Board:

Q: How can I expand the Banana Pi BPI-M2 Zero's functionality?

A: You can expand the board's functionality using the 40-pin GPIO header, which allows connection to multiple HATs, sensors, and compatible peripherals for diverse project requirements.

Q: What applications is the Banana Pi BPI-M2 Zero best suited for?

A: This development board excels in prototyping, embedded system design, IoT development, smart automation, and education, making it ideal for both commercial and academic settings.

Q: Where can the Banana Pi BPI-M2 Zero be deployed?

A: It's perfectly suited for controlled indoor environments such as research labs, classrooms, factories, and smart home setups, thanks to its compact size and flexible I/O.

Q: What is the process for installing an operating system on this board?

A: To install an OS, simply flash a supported Linux distribution (like Raspbian, Ubuntu, or Debian) or Android onto a MicroSD card, insert it into the board, and power up via Micro USB.

Q: How does the Banana Pi BPI-M2 Zero benefit prototyping work?

A: Its compact layout, wireless connectivity, and robust CPU/GPU enable fast iteration, reliable performance, and support for real-time debugging and development in various embedded and IoT projects.
