XH-M603 HW-632 Charging Control Module With LED Display

Name: XH-M603 HW-632 Charging Control Module With LED Display
Brand: ROBOTICS EMBEDDED EDUCATION SERVICES PRIVATE LIMITED
Price: 274 INR
Availability: InStock

Price 274 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

XH-M603 HW-632 Charging Control Module With LED Display Specification

Components
Onboard relay, digital LED display, terminal blocks, push buttons

Charging Voltage
Adjustable cut-off/restore voltage, 10-30V DC

Usage
Battery charging regulation for 12V/24V lead-acid or lithium batteries

Power Source
DC

Interface
Screw terminal connection

Input
10V-30V DC input

Features
Automatic charging control, adjustable cut-off voltage, restore charging threshold, digital display, simple wiring

Display Type
3-digit 7-segment LED display

Output
10V-30V DC (follows input voltage, relay controlled)

Power Supply
DC powered

Product Type
Lithium Battery

Application
Industrial

Rated Voltage
10-30 Volt (V)

Supply Voltage
DC 10-30V

Size
6.0 x 3.8cm

Dimension (L*W*H)
Approx. 6.0 x 3.8 x 1.8 cm

Function
Automatic battery charging control module with LED display

Color
Blue

Weight
Approx. 50g

Warranty
1 year

Thickness
Approx. 1.8cm

Capacity
Supports charging for batteries up to 20A (depends on relay rating)

Current Rating
Relay contact max 20A (Actual module commonly up to 10A)

Frequency
Relay switching frequency as per input

Mounting
PCB mounting holes provided

Humidity Range
5%~95% RH, non-condensing

Display Precision
±0.1V

PCB Material
FR4

IP Rating
Not rated (open PCB)

LED Indicator
Green (relay ON), Red (charging) LEDs

Model
XH-M603 HW-632

Configuration
Two-button setting interface

Operating Temperature
-40°C to +85°C

Suitable Batteries
Lead-acid, lithium, rechargeable battery types

Control Mode
Relay switching based on set voltage thresholds

Relay Type
Electromechanical relay

XH-M603 HW-632 Charging Control Module With LED Display About

Jump on the opportunity to upgrade battery management with the XH-M603 HW-632 Charging Control Module With LED Display. Highly recommended for industrial settings and battery regulation, it offers Stellar precision (0.1V) and Top-notch reliability. The sublime dual-button interface ensures easy configuration, while relay-based control automates charging with adjustable cut-off/restore voltage. LED indicators provide clear status updates, making monitoring effortless. Ending Soon - secure your module now for efficient, safe, and automated charging for lead-acid or lithium batteries. Suitable for 10-30V DC setups, this module is a must-have for optimal battery performance.

Versatile Application and Material Benefits

The XH-M603 HW-632 Charging Control Module is widely used by manufacturers, traders, wholesalers, and industrial operators across India. It's ideal for battery charging regulation, particularly for 12V/24V lead-acid or lithium batteries. Its robust FR4 PCB material ensures high stability in varied environments (5%~95% RH, -40C to +85C) and facilitates lasting, consistent performance. Two-button setting and digital LED display make this module user-friendly and adaptable to multiple industrial scenarios.

Swift Sampling and Reliable Global Supply

Sample availability makes it convenient for buyers to assess the XH-M603 HW-632 Charging Control Module before bulk purchasing. Shipped goods are securely packed and dispatched from FOB ports commonly in India, reaching domestic and export markets with ease. The supply ability is streamlined for bulk and trade needs, ensuring timely deliveries. Choose this module for peace of mind and smooth procurement, whether you're a distributor, exporter, importer, or manufacturer seeking reliable charging solutions.

FAQ's of XH-M603 HW-632 Charging Control Module With LED Display:

Q: How does the XH-M603 HW-632 Charging Control Module benefit battery charging?

A: It automates battery charging by switching a relay based on set voltage thresholds, ensuring optimal charging cycles for lead-acid and lithium batteries, while preventing overcharging.

Q: What is the maximum current rating supported by the onboard relay?

A: The onboard relay can handle contacts up to 20A, though the actual module typically supports charging currents commonly up to 10A, making it suitable for most battery capacities.

Q: What materials and controls make this module reliable for industrial use?

A: The module uses high-quality FR4 PCB material and features a two-button setting interface, digital LED display, and robust screw terminal connections for secure operation in industrial environments.

Q: Where is the XH-M603 HW-632 Charging Control Module typically shipped from?

A: Shipped goods often depart from FOB ports in India, serving both domestic markets and global export clients with secure shipping and timely supply.

Q: How can consumers request or receive samples of this charging control module?

A: Samples are available for potential buyers, allowing distributors or manufacturers to assess the module's suitability before committing to larger orders via streamlined export channels.

Q: What kind of batteries can be regulated with this module?

A: This module is compatible with 12V/24V lead-acid, lithium, and other rechargeable battery types, supporting automatic adjustment of charging cut-off and restore voltages up to 30V DC.
