Screw Shield V3 Terminal Expansion Board For Arduino Compatible UNO R3

Price 280 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Screw Shield V3 Terminal Expansion Board For Arduino Compatible UNO R3 Specification

Output
Digital and analog outputs accessible via terminals and headers

Power Supply
External DC power or USB

Sensors Specification
Not included

Input
Digital and analog inputs via screw terminals and pin headers

Power Source
Arduino board power supply

Usage
Simplifies wiring for sensors, modules, and external devices

Features
High-quality PCB, easy wiring, sturdy terminals, compatible with UNO R3

Components
Terminal block connectors, PCB, female socket headers

Interface
Screw terminals, female headers

Operating Temperature
-20C to +70C

Product Type
Screw Terminal Block

Application
Industrial

Rated Voltage
3.3- 5 Volt (V)

Supply Voltage
3.3V/5V

Size
Fits Arduino UNO R3 standard board

Dimension (L*W*H)
76mm x 53mm x 19mm (approx)

Function
Provides screw terminal connection to all Arduino UNO R3 I/O pins

Color
Red

Weight
Approximately 45g

Warranty
1 year

Thickness
1.6mm PCB

Current Rating
Maximum 2A per terminal

Capacity
Supports all UNO R3 pin connections

PCB Material
FR-4 flame-retardant material

Protection
Short-circuit and reverse-polarity protection by design

RoHS Compliance
Yes, eco-friendly manufacturing

Terminal Type
Pluggable, with secure screw clamps

Mounting Type
Direct stack-up on Arduino UNO R3

Number of Terminals
28 screw terminals supporting all UNO R3 pins

Wire Gauge Supported
22-28 AWG

Product Compatibility
Compatible with Arduino UNO R3 and similar boards

About Screw Shield V3 Terminal Expansion Board For Arduino Compatible UNO R3

Buy the Screw Shield V3 Terminal Expansion Board for Arduino UNO R3 and unleash invincible versatility for your projects! Designed with 28 gorgeous screw terminals, it supports all UNO R3 pins, making connections straightforward and secure. Engineered with a meritorious FR-4 flame-retardant PCB and robust pluggable terminals, this eco-friendly, RoHS-compliant board offers short-circuit and reverse-polarity protection by design. Compatible with Arduino UNO R3 and similar models, it's perfect for industrial applications and simplifies wiring for sensors, modules, and external devices. Order today for effortless integration and reliable performance!

Versatile Industrial Applications and Usage Methods

Screw Shield V3 Terminal Expansion Board For Arduino Compatible UNO R3 is ideally used as an interface bridge for seamless wiring in industrial environments. Its straightforward stack-up mounting allows effortless direct installation onto the UNO R3, streamlining connections for sensors, input devices, and external modules. Commercially, it's favored in automation setups, prototype development, and educational institutions for practical learning. This board excels by providing secure input/output connectivity, making large-scale deployment in commercial and industrial projects truly convenient.

Sample Policy, Supply Capacity, and Sample Availability

Our Screw Shield V3 Terminal Expansion Board offers a flexible sample policy where interested parties can obtain a sample with a nominal charge. Once the outlay is settled, we ensure swift handover of the requested samples. With strong supply ability, we cater to distributors, importers, exporters, wholesalers, and suppliers across India. Quickly scale your operations-just request a sample to validate quality before placing a bulk order, and we'll support you every step of the way.

FAQ's of Screw Shield V3 Terminal Expansion Board For Arduino Compatible UNO R3:

Q: How do I mount the Screw Shield V3 Terminal Expansion Board onto my Arduino UNO R3?

A: The board is designed for a direct stack-up mounting on your Arduino UNO R3. Simply align the headers and press it gently onto the board, ensuring all pins are connected for secure operation.

Q: What benefits does the Screw Shield V3 Terminal Expansion Board provide for industrial or educational projects?

A: It simplifies wiring through pluggable screw terminals, offers robust protection against short circuits and reverse polarity, and supports versatile sensor or module integration-making it ideal for both industrial automation and hands-on learning environments.

Q: Where can I use the Screw Shield V3 Terminal Expansion Board in commercial settings?

A: This expansion board is suitable for use in automation control panels, prototype developments, laboratory setups, and any commercial environment where streamlined, secure wiring to Arduino UNO R3 boards is required.

Q: What is the supply voltage and maximum current rating for each terminal?

A: The board operates at a supply voltage of 3.3V or 5V, and each terminal can safely handle a maximum current of 2A, ensuring compatibility with a wide range of industrial and educational sensors and modules.

Q: What does the sample provision process involve and is there a charge?

A: Samples are available for a nominal charge. After covering the minimal outlay, you can expect prompt handover of the sample, allowing you to test the board before making a bulk purchase.

Tell us about your requirement
