NDIR CO2 Sensor MH-Z14A PWM NDIR

Price 3389 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

NDIR CO2 Sensor MH-Z14A PWM NDIR Specification

Measurement Range
0~5000 ppm (default 0~2000 ppm)

Sensitivity
1 ppm

Sensor Type
Non-Dispersive Infrared (NDIR)

Cable Length
Depends on application (not provided in sensor)

Operating Temperature
0C to 50C

Power Consumption
< 60 mA (operating)

Features
High selectivity; long lifespan; built-in temperature compensation; compact size; maintenance-free

Response Time
T90 < 120s

Interface
PWM, UART, Analog voltage output

Mounting Type
PCB Mount

Signal Type
Digital (PWM, UART) / Analog

IP Rating
IP44

Application
HVAC, air quality monitoring, greenhouse, and industrial applications

Wireless
No

Product Type
NDIR CO2 Sensor MH-Z14A PWM NDIR

Material
pcb Fiber

Input
Air sample (via diffusion or pumped)

Output
PWM, UART (Serial), Analog

Function
Detection and measurement of CO2 concentration using NDIR technology

Usage
Industrial

Accuracy
(50ppm + 5% of reading)

Resolution
1 ppm

Voltage
5 Volt (v)

Weight
14g

Warranty
1 Year

Detection Principle
Non-Dispersive Infrared (NDIR) absorption spectroscopy

Preheating Time
3 min

Storage Temperature
-20C to 60C

Humidity Range
0 to 95% RH (non-condensing)

Size
57 35 15 mm

Output Impedance
<100

Life Span
>5 years (in normal indoor environment)

Warm-Up Time
< 3 minutes

Pressure Range
Standard atmospheric pressure 10%

About NDIR CO2 Sensor MH-Z14A PWM NDIR

Experience the prodigious performance of the NDIR CO2 Sensor MH-Z14A PWM NDIR. With matchless accuracy (50ppm + 5% of reading) and splendiferous durability-over 5 years lifespan-this compact sensor (573515 mm, 14g) is engineered for industrial superiority. Featuring high selectivity, built-in temperature compensation, and maintenance-free operation, it seamlessly integrates via PWM, UART, or analog outputs. Fulfill HVAC, air quality monitoring, greenhouse, and industrial requirements with confidence. Enjoy competitive pricing and comprehensive warranty. Order today and elevate your operations with unrivaled technology-distribution available across India.

NDIR CO2 Sensor MH-Z14A PWM NDIR: Versatile Commercial Applications

Designed for industrial environments, the NDIR CO2 Sensor MH-Z14A PWM NDIR is used widely in HVAC systems, air quality monitoring, and greenhouse management. Its robust non-dispersive infrared technology guarantees precision and reliability, making it highly suitable for continuous monitoring in factories, laboratories, and smart buildings. Its compact size and flexible mounting options ensure seamless integration, elevating commercial operations with efficient and splendiferous performance.

Main Domestic Market, Sample Policy & Certification Details

Targeted at the Indian market, the NDIR CO2 Sensor MH-Z14A PWM NDIR provides secure drop-off and offer options for sample acquisition upon request. Packaging is thoughtfully done to ensure the safe delivery and handling of each sensor. Certifications assure quality, reliability, and compliance with industry standards, supporting distributor, exporter, importer, manufacturer, supplier, trader, and wholesaler requirements. Trust this certified sensor for matchless domestic and professional applications.

FAQ's of NDIR CO2 Sensor MH-Z14A PWM NDIR:

Q: How does the NDIR MH-Z14A sensor measure CO2 concentration?

A: The sensor uses Non-Dispersive Infrared (NDIR) absorption spectroscopy, effectively detecting and measuring CO2 by analyzing infrared light absorption in the air sample.

Q: What are the main usage applications for the MH-Z14A?

A: This sensor is primarily used in industrial environments, including HVAC control, air quality monitoring, and greenhouse management, ensuring optimal air standards and operational efficiency.

Q: When should the sensor be preheated before operation?

A: A preheating time of three minutes is recommended before starting measurements to ensure accurate readings and optimal sensor performance.

Q: Where can the MH-Z14A sensor be installed?

A: Thanks to its compact PCB mount design, it can be installed in control panels, industrial machinery, environmental monitoring setups, and HVAC systems.

Q: What certifications and warranty do you offer for the product?

A: The MH-Z14A comes with quality certifications affirming adherence to industry standards and includes a one-year warranty for added assurance.

Q: How does the drop-off and packaging process work for sample orders?

A: Sample orders benefit from secure packaging and a streamlined drop-off process, ensuring the sensor arrives safely and promptly for evaluation.
